The Photovoltaic Solar Kit 3000W 24V 6400Whdia, energy consumption system for lighting and electrical equipment for sporadic use.
Characteristics of the 3000W 24V 6400Whdia Photovoltaic Solar Kit system
The photovoltaic system provided in the attachment can generate 4.86 kWh per day in winter (3 hours of sunshine) and 11.34 kWh in summer (7 hours of sunshine).
The characteristics of the proposed system are the following:
Installed solar generation: 1,620 W
Maximum output power to the box: 3000W
Daily production in winter: 4.86 kWh
Summer: daily production: 11.34 kWh
Annual average daily production: 8.10 kWh
Components of the Photovoltaic Solar Kit 3000W 24V 6400Whdia
4 x Solar Panel 405W Deep Blue 3.0 JA Solar Mono: they have very special properties. It contains a half cell that provides a very high level of efficiency with a power of 405W. Powered by PERC technology and supplied by world renowned manufacturer JA Solar.
1 x Structure 4 Panels 30-45mm Coplanar Falcat: support to allow the placement of 4 solar panels on the roof with the correct slope and orientation. The panels are placed perpendicular to the structure and have the same slope as the surface on which they are installed. In this case, the structure is designed for panels of any length and has a universal press that accepts panel profiles from 30 to 45 mm. This is the most suitable type of construction for metal roofs, sandwich panels or concrete slab roofs. The product is supplied in a single package and can be connected to multiple structures of the same type using the appropriate connection kit.
2 x AGM 12V 300Ah Tensite Battery: high capacity monoblock batteries that do not emit gases and do not require maintenance. This is a great option if you plan to install the battery in an area with no ventilation. It is recommended to install it in a natural position. Never connect in parallel. It’s a great battery with a 2-year manufacturer’s warranty.
1 x Must Solar 3000W 24V Inverter Charger Pre-Assembled with Guards – This is a pre-assembled kit containing the Must Solar 3000W 24V Isolated Inverter which provides up to 3000W of output power from a 24V battery. The inverter has an input for the solar panel and is used to supply power and charge the 24V battery. This energy passes through an internal MPPT type charge controller with a charging power of 50A and is used to boost the battery charge and make it ready for use. A 24V battery charger with a charging force of up to 30A is also included in case you need to charge the battery using a compatible generator or external power source. The entire set is pre-assembled and wired on a metal plate that can be easily hung on the wall. Simply connect the input of the solar panel to the corresponding input of the fuse that protects it, and connect the load to the output of the circuit breaker. The iron shield should be placed high enough so that the battery cables can reach the battery terminals well.
1 x Roll Unifilar Cable 6mm2 H1Z2Z2-K 5m red: special for electrical installations. Halogen-free flexible power cables for the most demanding industrial requirements.
1 x Roll Unifilar Cable 6mm2 H1Z2Z2-K 5m black: special for electrical installations. Halogen-free flexible power cables for the most demanding industrial requirements.
1 x Roll 10mm2 Single Wire Cable H1Z2Z2-K 10m red: special for electrical installations. Halogen-free flexible power cables for the most demanding industrial requirements.
1 x Roll of Single Wire Cable 10mm2 H1Z2Z2-K 10m black: special for electrical installations. Halogen-free flexible power cables for the most demanding industrial requirements.
3 x WEIDMULLER PVStick Connectors – Most recommended if you don’t have crimping tools that can connect regular MC4 connectors. They are compatible with all connector models that come standard with solar panels and do not require tools to connect to the cable.
1 x Battery Interconnection Cable: measured at the terminals provided, depending on the diameter of the battery screw to be connected. It has all the technical properties that allow the batteries to be interconnected in complete safety.
1 x Parallel Connectors 2 Flexible MC4 PV Panels: ideal for connecting up to 2 modules in parallel in a photovoltaic system.
