The Solar Kit 1600VA 12V 5000Whdia, a small energy system to power your refrigerator, television or lights.
Characteristics of the Solar Kit 1600VA 12V 5000Whdia system
The photovoltaic system provided in the attached file can generate 3.00 kWh per day in winter (3 hours of sunshine) and 7.00 kWh in summer (7 hours of sunshine).
The characteristics of the proposed system are the following:
Installed solar generation: 1,000 W
Maximum output power to housing: 1600VA
Daily production in winter: 3.00 kWh
Summer: daily production: 7.00 kWh
Annual average daily production: 5.00 kWh
Solar Kit Components 1600VA 12V 5000Whdia
5 x MUST 200W 12V Monocrystalline Solar Panel: suitable for caravans and 12V installations. It consists of 32 monocrystalline cells, weighs 10.3 kg and has dimensions of 1290 x 760 x 30 mm. The efficiency of the module is 20.4%, making it a very good option for small isolated houses with 3 or 4 panels and a 12V battery installed.
1 x Structure 5 Panels 30-45mm Coplanar Falcat: support to allow the placement of 5 solar panels on the roof with the correct slope and orientation. The panels are placed perpendicular to the structure and have the same slope as the surface on which they are installed. In this case, the structure is designed for panels of any length and has a universal press that accepts panel profiles from 30 to 45 mm. This is the most suitable type of construction for metal roofs, sandwich panels or concrete slab roofs. The product is supplied in a single package and can be connected to multiple structures of the same type using the appropriate connection kit.
1 x Ultracell UCG-316-12 12V 316Ah GEL Battery: from top brands like Ultracell, this GEL battery ensures maximum performance and durability of your solar kit. This is a deep cycle and represents the best in lead-acid battery technology with a GEL electrolyte. Life expectancy is over 1,200 cycles, but battery life can easily be doubled with less than 30% discharge, easily over 2,000 cycles. The GEL electrolyte is maintenance free and does not out gas, making it a very safe battery for indoor use. The battery has F1 screw terminals and weighs approximately 73 kg.
1 x 12V / 24V 60A PWM Must Solar Regulator: The 60A charge controller works with a 12V DC or 24V DC battery and receives all battery charging information (general operating status, battery voltage, produced current and temperature) of the panel.Includes an LCD screen. to show In addition, this 10A solar charge controller from the manufacturer Must Solar can be easily configured to accurately charge your battery regardless of technology, ensuring perfect results and long battery life. It features a 12Vdc or 24Vdc output for DC-powered charging, 2 USB ports for charging mobile devices, and offers a 2-year manufacturer’s warranty. The charge controller has protection against PV array short circuit, PV reverse connection, battery reverse connection, overload and output short circuit. Available from 10A to 60A in 12V DC and 24V DC models.
1 x Victron Multiplus 12V 1600VA 70+16A inverter: includes charger with integrated switch. This compact Victron Multiplus inverter guarantees reliability and performance. Low consumption, very useful for uninterruptible power supply systems, telecommunications, boats, etc. It has a peak wattage that effectively doubles the constant power output, making it a great choice among devices that not only act as an inverter, but also have a built-in charger.
1 x Roll Unifilar Cable 6mm2 H1Z2Z2-K 10m red: special for electrical installations. Halogen-free flexible power cables for the most demanding industrial requirements.
1 x Roll Unifilar Cable 6mm2 H1Z2Z2-K 10m black: special for electrical installations. Halogen-free flexible power cables for the most demanding industrial requirements.
10 x Unifilar Cable 16 mm2 SOLAR PV ZZ-F Red: special for electrical installations. Halogen free power cable. It is a flexible power cable designed to meet the most demanding industrial needs.
10 x Unifilar Cable 16 mm2 SOLAR PV ZZ-F Black: special for electrical installations. Halogen free power cable. It is a flexible power cable designed to meet the most demanding industrial needs.
1 x 35 mm2 POWERFLEX RV-K Green single-core cable: POWERFLEX RV-K Solid Green 35 mm² Cables are specially designed for electrical installations. Low halogen power cable. Flexible cables designed to meet the most demanding industrial needs such as low voltage industrial connections, urban networks and indoor installations.
1 x 35 mm2 POWERFLEX RV-K Black single-core cable: the 35mm2 POWERFLEX RV-K Black Single-core Cable is specially designed for electrical installations. Low halogen power cable. Flexible cables designed to meet the most demanding industrial needs such as low voltage industrial connections, urban networks and indoor installations.
1 x Watertight Box 150x110x70mm: ideal for installing the Legrand power distributor inside. Both 40A and 100A are available for large installations.
1 x 100A Modules Parallel Connection Splitter: perfect for connecting the cables coming out of your solar panels to a splitter. From now on, only two wires (one positive and one negative) can go to the charge controller. Get significant savings on cable meters.
2 x 16mm Cable Eye Terminal – 8mm Eye: used to crimp 16mm gauge cables and connect 8mm diameter screws.
5 x WEIDMULLER PVStick Connectors – Most recommended if you don’t have crimping tools that can connect normal MC4 connectors. They are compatible with all connector models that come standard with solar panels and require no tools to connect to the cable.
2 x 35mm Cable Eye Terminal – 8mm Eye: used to crimp 35mm gauge cables and connect 8mm diameter screws.
